1. What Is the C Preprocessor?

The C preprocessor runs before the compiler. It reads your source code and processes all lines starting with # (called preprocessor directives).

2. #include – Bringing in Declarations

You have seen lines like:

#include <stdio.h>
#include <stdlib.h>

These tell the preprocessor to copy the contents of the header files (stdio.h, stdlib.h) into your source file at that point.

Two forms of #include

Example: user-defined header

sensor.h

#ifndef SENSOR_H
#define SENSOR_H

float read_voltage(void);
float read_current(void);

#endif // SENSOR_H

main.c

#include <stdio.h>
#include "sensor.h"

int main() {
    printf("V = %.1f, I = %.2f\\n", read_voltage(), read_current());
    return 0;
}

The include guard pattern (#ifndef, #define, #endif) prevents the same header from being included multiple times in one compilation unit.

3. #define – Symbolic Constants (Object-like Macros)

The simplest use of #define is to define constants:

#define PI 3.14159
#define MAX_STUDENTS 100
#define SITE_VOLTAGE 415

Whenever the preprocessor sees PI in your code, it replaces it with 3.14159 (simple text substitution).

Technician-style example: configuration constants

#define MAX_INVERTERS 34
#define NOMINAL_AC_VOLTAGE 230.0
#define LOG_FILE "site_log.txt"

Then in code:

float voltage[MAX_INVERTERS];
printf("Nominal voltage: %.1f V\\n", NOMINAL_AC_VOLTAGE);
fp = fopen(LOG_FILE, "a");

const float NOMINAL_AC_VOLTAGE = 230.0f;

4. Function-like Macros – Small Inline Patterns

Macros can also take parameters (like functions), but they are still text-substitution:

#define SQUARE(x) ((x) * (x))

Usage:

int a = 5;
int s = SQUARE(a + 1);   // expands to ((a + 1) * (a + 1))

Why use extra parentheses?

Without parentheses:

#define BAD_SQUARE(x) x * x
int s = BAD_SQUARE(a + 1);   // becomes a + 1 * a + 1 (wrong)

Using ((x) * (x)) ensures correct order of operations.

Technician-style macro examples

#define VOLT_TO_KW(v, i)   ((v) * (i) / 1000.0f)
#define IS_OVER_LIMIT(v, limit)  ((v) > (limit))

In code:

float v = 230.0f, i = 12.5f;
float power = VOLT_TO_KW(v, i);  // 2.875 kW approx

if (IS_OVER_LIMIT(v, NOMINAL_AC_VOLTAGE + 10.0f)) {
    printf("Voltage over limit!\\n");
}

5. Macro Pitfalls & Best Practices

6. Conditional Compilation – #if, #ifdef, #ifndef, #elif, #endif

Conditional compilation lets you enable or disable blocks of code at compile time based on conditions. This is extremely useful for:

• Debug vs release builds (extra logs, assertions).
• Different hardware boards or sites.
• Enabling or disabling experimental features.

Basic forms

#if condition
    // code
#elif other_condition
    // other code
#else
    // fallback
#endif

#ifdef MACRO_NAME
    // code if MACRO_NAME is defined
#endif

#ifndef MACRO_NAME
    // code if MACRO_NAME is NOT defined
#endif

Example: debug logging macro

#define DEBUG   // comment this line to disable debug

#ifdef DEBUG
    #define LOG(msg)  printf("DEBUG: %s\\n", msg)
#else
    #define LOG(msg)  // expands to nothing
#endif

int main() {
    LOG("Program started");
    // ...
    LOG("Program finished");
    return 0;
}

If DEBUG is defined, LOG("...") prints messages. If not, the macro expands to nothing and the debug code is removed from the compiled binary.

Technician-style example: site configuration

#define SITE_A
// #define SITE_B

#ifdef SITE_A
    #define SITE_NAME   "Nandhavanapatti"
    #define MAX_MW      10
#elif defined(SITE_B)
    #define SITE_NAME   "Another Solar Site"
    #define MAX_MW      5
#else
    #define SITE_NAME   "Unknown Site"
    #define MAX_MW      1
#endif

printf("Running config for %s (%d MW)\\n", SITE_NAME, MAX_MW);

7. Header Guards & #pragma once

If a header file is included multiple times (directly or indirectly), you can get duplicate-definition errors. To prevent this, we use header guards.

Standard pattern (portable)

#ifndef CONFIG_H
#define CONFIG_H

#define FW_VERSION "1.0.3"
#define MAX_INVERTERS 34

#endif // CONFIG_H

Here, if CONFIG_H is not yet defined, the block is included and CONFIG_H is defined. On subsequent includes, CONFIG_H is already defined so the content is skipped.

#pragma once (non-standard but common)

#pragma once

#define FW_VERSION "1.0.3"
#define MAX_INVERTERS 34

#pragma once tells the compiler to include the file only once. It is widely supported but not part of the C standard; header guards are fully portable.

8. #undef and Other Useful Directives

#undef – Cancel a Macro

#define TEMP_LIMIT 60

// ... some code

#undef TEMP_LIMIT   // macro is no longer defined here

After #undef TEMP_LIMIT, the name TEMP_LIMIT no longer expands as a macro.

#error – Generate a Compile-Time Error

#ifndef SITE_NAME
    #error "SITE_NAME is not defined! Please set site configuration."
#endif

This is useful to catch missing configuration at compile time instead of discovering it in runtime.

9. Real Use Cases – Technicians & Embedded C Style

9.1 Board-specific code

#define BOARD_V1
// #define BOARD_V2

#ifdef BOARD_V1
    #define RELAY_PIN 5
#elif defined(BOARD_V2)
    #define RELAY_PIN 12
#else
    #define RELAY_PIN 0
#endif

Now the rest of the code can use RELAY_PIN without if–else everywhere.

9.2 Enabling extra diagnostics only in development builds

#ifdef DEBUG
    #define DIAG_PRINT(fmt, ...) \
        printf("DIAG: " fmt "\\n", ##__VA_ARGS__)
#else
    #define DIAG_PRINT(fmt, ...)  // nothing
#endif

In production, you simply compile without DEBUG defined and your binaries are smaller and faster.

10. Learning Checklist – Preprocessor & Macros

• I know that the preprocessor runs before the actual C compilation.
• I understand how #include brings in declarations from header files.
• I can use #define for symbolic constants and simple macros.
• I know the difference between object-like macros and function-like macros.
• I can write safe macros with proper parentheses and without side-effect arguments.
• I can use #if, #ifdef, #ifndef, #elif, #endif for conditional compilation.
• I know how header guards work and why they are important.
• I understand when to prefer const or functions instead of complex macros.
